| Nama Wahi | S039WQ01 |
| Waitohu | CDTECH |
| Rahi | 3.9 |
| Taupānga | Industrial Stretched |
| Whakatau | 480×128 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 16.7M |
| Whakamuri | 5S2P |
| Atanga | |
| manufacturer | CDTECH |
| model name | S039WQ01 |
| screen size | 3.9 inch (1/2 cut of 4.3") |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 480(RGB)×128 128PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 95.04 × 25.34 (H×V) |
| outline(mm) | 105.5 × 40.64 × 3.15 (H×V×D) |
| bezel area(mm) | 98.04 × 28.34 (H×V) |
| treatment | - |
| luminance | 500 cd/m² (Typ.) |
| contrast ratio | 500 : 1 (Typ.) (TM) |
| viewing angle | 65/65/55/65 (Typ.)(CR≥10) |
| response | 10/15 (Typ.)(Tr/Td) ms |
| good view at | 12 o'clock |
| work mode | TN, Normally White, Transmissive |
| color depth | 16.7M 50% NTSC |
| backlight | 5S2P WLED , 30K hours , No Driver |
| mass | TBD |
| used for | Industrial Stretched Bar LCD Automotive Display |
| refresh rate | - |
| touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
