RiTdisplay RGS15128128YR000 Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com

RGS15128128YR000


Waitohu
RiTdisplay
Rahi
1.5
Taupānga
IA
Whakatau
128×128
Te tito
OLED
Tirohanga
100
CR
2000:1
Nga Tae
Mono(Yellow)
Whakamuri
self
Atanga
CPU/SPI/I²C
In Stock
18796
Whakatakotoranga

Nama Wahi RGS15128128YR000
WaitohuRiTdisplay
Rahi1.5
TaupāngaIA
Whakatau128×128
Te titoOLED
Tirohanga100
CR2000:1
Nga TaeMono(Yellow)
Whakamuriself
AtangaCPU/SPI/I²C
panel brandRiTdisplay
panel modelRGS15128128YR000
panel type PM-OLED , OLED
panel size1.5 inch
resolution128×128
active area26.86×26.86 mm
outline33.8×36.5×1.51 mm
surfaceAntiglare
brightness100 cd/m² (Typ.)
contrast ratio2000 : 1 (Min.)
display colorsMono(Yellow) (1-bit)
viewing angle80/80/80/80 (Min.)(L/R/U/D)
frequency105Hz
driver icCOG Built-in SSD1327
signal interface8-bit 6800/8080 parallel, SPI, I²C, 25 pins
input voltage15V (Typ.)(VCC)
applicationIA
