| Nama Wahi | QV116FHB-N83-1QP0 |
| Waitohu | BOE |
| Rahi | 11.6 |
| Taupānga | Digital Signage |
| Whakatau | 1920×1080 |
| Te tito | CELL , a-Si TFT-LC |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | No |
| Atanga | eDP |
| manufacturer | BOE |
| model name | QV116FHB-N83-1QP0 |
| screen size | 11.6 inch |
| screen type | CELL , a-Si TFT-LCD |
| pixel number | 1920(RGB)×1080 (FHD) 190PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 256.32 × 144.18 (H×V) |
| outline(mm) | 261.62 × 155.3 × 1.16 (H×V×D) |
| bezel area(mm) | - |
| treatment | Clear, Hard coating (3H) |
| luminance | 0 cd/m² |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| response | 30 (Typ.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | ADS, Normally Black, Transmissive |
| glass thickness | 0.40+0.40 mm |
| transmissivity | 4.2% (Typ.) |
| color depth | 16.7M 72% NTSC |
| backlight | No B/L , With LED Driver |
| mass | 103g |
| used for | Digital Signage |
| refresh rate | 60Hz |
| touchscreen | Without |
| driver ic list | Built-in COG 4 source chips |
| signal type | eDP (2 Lanes) , 30 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
