| Nama Wahi | QD14TL01 Rev.04 |
| Waitohu | QDI |
| Rahi | 14.1 |
| Taupānga | NBPC |
| Whakatau | 1280×800 |
| Te tito | LCM |
| Tirohanga | 185 |
| CR | 300:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | QDI |
| panel model | QD14TL01 Rev.04 9 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 14.1 inch |
| resolution | 1280(RGB)×800 , WXGA |
| display mode | TN, Normally White, Transmissive |
| active area | 303.74×189.84 mm |
| outline | 319.5×218×5.5 mm |
| shape style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| surface | Antiglare, Hard coating (3H) |
| brightness | 185 cd/m² (Typ.) |
| contrast ratio | 300:1 (Typ.) |
| display colors | 262K (6-bit) |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 40/40/10/30 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| input voltage | 3.3V (Typ.) |
| application | NBPC |
| B141XG09 V0 | AUO | 14.1 | 1024×768 |
| B141XN03 V0 | AUO | 14.1 | 1024×768 |
| HT141WXB-100 | BOE | 14.1 | 1280×800 |
| LT141X7-124 | Samsung | 14.1 | 1024×768 |
| LTM14C421F | TOSHIBA | 14.1 | 1024×768 |
| LTN141BT01-004 | Samsung | 14.1 | 1440×900 |
| LTN141X4-156 | Samsung | 14.1 | 1024×768 |
| LTN141XF-L03 | Samsung | 14.1 | 1024×768 |
| NL10276BC28-21A | NLT | 14.1 | 1024×768 |
| QD14TL01 Rev.04 | QDI | 14.1 | 1280×800 |
| B141EW02 V3 | AUO | 14.1 | 1280×800 |
| LP140WF1-SPJ1 | LG Display | 14.0 | 1920×1080 |
| LP141WP1-TLC3 | LG Display | 14.1 | 1440×900 |
| LP141WX3-TLA4 | LG Display | 14.1 | 1280×800 |
| LP154WP4-TLA1 | LG Display | 15.4 | 1440×900 |
| LTD131EWSX | TOSHIBA | 13.1 | 1366×768 |
| LTN125AT03-803 | Samsung | 12.5 | 1366×768 |
| LTN173KT01-D01 | Samsung | 17.3 | 1600×900 |
| LTN173KT01-W04 | Samsung | 17.3 | 1600×900 |
| N141I3-L05 | Innolux | 14.1 | 1280×800 |
