Nama Wahi | PV190E0M-N10 |
Waitohu | BOE |
Rahi | 19.0 |
Taupānga | Industrial |
Whakatau | 1280×1024 |
Te tito | LCM , a-Si TFT-LCD |
Tirohanga | |
CR | 1000:1 |
Nga Tae | 16.7M |
Whakamuri | WLED |
Atanga | |
manufacturer | BOE |
screen size | 19.0 inch |
pixel number | 1280(RGB)×1024 (SXGA) 86PPI |
active area(mm) | 374.784 × 299.827 (H×V) |
bezel area(mm) | 379 × 303 (H×V) |
luminance | 400 (Typ.)(cd/m²) |
viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
good view at | Symmetry |
color depth | 16.7M 73% NTSC |
mass | 1.95Kgs (Typ.) |
refresh rate | 60Hz |
model name | PV190E0M-N10 |
screen type | LCM , a-Si TFT-LCD |
arrangement | RGB Vertical Stripe |
outline(mm) | 396 × 324 × 12.13 (H×V×D) |
treatment | Antiglare (Haze 25%), Hard coating (3H) |
contrast ratio | 1000 : 1 (Typ.) (TM) |
work mode | ADS, Normally Black, Transmissive |
response | 14 (Typ.)(G to G) ms |
backlight | WLED , 50K hours , No Driver |
used for | Industrial |
touchscreen | Without |
G190ETN01.1 | AUO | 19.0 | 1280×1024 |
LM190E08-TLGD | LG Display | 19.0 | 1280×1024 |
LTM190BT03 | Samsung | 19.0 | 1440×900 |
M190A1-L07 | Innolux | 19.0 | 1440×900 |
M190EN01 V1 | AUO | 19.0 | 1280×1024 |
M190EN04 V5 | AUO | 19.0 | 1280×1024 |
M190PW01 V0 | AUO | 19.0 | 1440×900 |
M190PW01 V8 | AUO | 19.0 | 1440×900 |
MT190AW02 V.A | Innolux | 19.0 | 1440×900 |
MT190EN02 V.W | Innolux | 19.0 | 1280×1024 |
