Nama Wahi | NV133FHM-N68 |
Waitohu | BOE |
Rahi | 13.3 |
Taupānga | Laptop |
Whakatau | 1920×1080 |
Te tito | a-Si TFT-LCD, LCM |
Tirohanga | |
CR | 1000:1 |
Nga Tae | 16.2M |
Whakamuri | 9S4P |
Atanga | eDP |
panel brand | BOE |
panel model | NV133FHM-N68 (BOE0898) |
panel size | 13.3" |
panel type | a-Si TFT-LCD, LCM |
resolution | 1920(RGB)×1080, FHD, 166PPI |
pixel format | RGB Vertical Stripe |
display area | 293.76(W)×165.24(H) mm |
bezel opening | - |
outline size | 300.26(W)×177.35(H) ×4.35(D) mm |
surface | Antiglare, Hard coating (3H) |
brightness | 250 cd/m² (Typ.) |
contrast ratio | 1000:1 (Typ.) (TM) |
viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
display mode | ADS, Normally Black, Transmissive |
best view on | Symmetry |
response time | 30 (Typ.)(Tr+Td) |
display colors | 16.2M 45% NTSC |
lamp type | 9S4P WLED , 15K hours , With LED Driver |
frequency | 60Hz |
touch screen | Without |
shape style | Slim (PCBA Bent, T≤3.0mm) |
application | Laptop |
signal interface | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
input voltage | 3.3V (Typ.) |
environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
