| Nama Wahi | NV101WUM-N52 |
| Waitohu | BOE |
| Rahi | 10.1 |
| Taupānga | Pad & Tablet |
| Whakatau | 1200×1920 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | MIPI |
| manufacturer | BOE |
| screen size | 10.1 inch |
| pixel number | 1200(RGB)×1920 (WUXGA) 225PPI |
| active area(mm) | 135.36 × 216.576 (H×V) |
| luminance | 400 cd/m² (Typ.) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| good view at | Symmetry |
| color depth | 16.7M 68% NTSC |
| mass | 132g (Typ.) |
| refresh rate | 60Hz |
| signal type | MIPI (4 data lanes) , 42 pins Connector |
| voltage supply | 1.8/3.3V (Typ.)(VDD1/VDD3) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| model name | NV101WUM-N52 |
| screen type | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 141.56 × 228.226 × 4.2 (H×V×D) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| response | 35 (Max.)(Tr+Td) ms |
| work mode | ADS, Normally Black, Transmissive |
| backlight | WLED , 15K hours , No Driver |
| used for | Pad & Tablet |
| touchscreen | Without |
