| Nama Wahi | NL6448AC33-A0D |
| Waitohu | NLT |
| Rahi | 10.4 |
| Taupānga | Industrial |
| Whakatau | 640×480 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 900:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | CMOS |
| panel brand | NLT |
| panel size | 10.4" |
| resolution | 640(RGB)×480, VGA, 76PPI |
| display area | 211.2(W)×158.4(H) mm |
| outline size | 246.5(W)×179.4(H) ×10(D) mm |
| brightness | 500 cd/m² (Typ.) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| best view on | - |
| display colors | 262K 40% NTSC |
| frequency | 60Hz |
| panel weight | 390/435g (Typ./Max.) |
| signal interface | CMOS (1 ch, 6-bit) , 31 pins Connector |
| input voltage | 3.3/5.0V (Typ.) |
| environment | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| panel model | NL6448AC33-A0D |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | - |
| surface | Antiglare, Hard coating (3H) |
| contrast ratio | 900:1 (Typ.) (TM) |
| display mode | TN, Normally White, Transmissive |
| response time | 3/15 (Typ.)(Tr/Td) |
| lamp type | WLED , 100K hours , With LED Driver |
| touch screen | Without |
| application | Industrial |
