| Nama Wahi | NL12880BC20-25F |
| Waitohu | NLT |
| Rahi | 12.1 |
| Taupānga | Industrial Outdoor H |
| Whakatau | 1280×800 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | 3 |
| Atanga | LVDS |
| manufacturer | NLT |
| model name | NL12880BC20-25F |
| screen size | 12.1 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 1280(RGB)×800 (WXGA) 124PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 261.12 × 163.2 (H×V) |
| outline(mm) | 277.7 × 180.6 × 9.2 (H×V×D) |
| bezel area(mm) | 266.1 × 168.2 (H×V) |
| treatment | Antiglare, Hard coating (3H) |
| luminance | 1600 cd/m² (Typ.) |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| response | 15 (Typ.)(Tr+Td) ms |
| good view at | 6 o'clock |
| work mode | TN, Normally White, Transmissive |
| color depth | 262K/16.7M 50% NTSC |
| backlight | 3 strings WLED , 60K hours , No Driver |
| mass | 470g (Typ.) |
| used for | Industrial Outdoor High Brightness |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (1 ch, 6/8-bit) , Connector 20 pins |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.0G (19.6 m/s²) |
