BOE NE133QUM-N42 Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com

NE133QUM-N42


Waitohu
BOE
Rahi
13.3
Taupānga
Laptop
Whakatau
3840×2160
Te tito
LCM ,   Oxide TFT-LC
Tirohanga
CR
1000:1
Nga Tae
16.7M
Whakamuri
9S5P
Atanga
eDP
In Stock
17096
Whakatakotoranga

Nama Wahi NE133QUM-N42
WaitohuBOE
Rahi13.3
TaupāngaLaptop
Whakatau3840×2160
Te titoLCM ,   Oxide TFT-LC
Tirohanga
CR1000:1
Nga Tae16.7M
Whakamuri9S5P
AtangaeDP
manufacturerBOE
model nameNE133QUM-N42 (BOE08CA)
screen size13.3 inch
screen typeLCM ,   Oxide TFT-LCD
pixel number3840(RGB)×2160   (UHD)  332PPI
arrangementRGB Vertical Stripe
active area(mm)293.76 × 165.24 (H×V)
outline(mm)298.76 × 176.42 × 4.6 (H×V×D)
bezel area(mm)-
treatmentAntiglare (Haze 25%), Hard coating (3H)
luminance300 cd/m² (Typ.)
contrast ratio1000 : 1 (Typ.) (TM)
viewing angle89/89/89/89 (Typ.)(CR≥10)
response30 (Typ.)(Tr+Td) ms
good view atSymmetry
work modeADS, Normally Black, Transmissive
color depth16.7M   100% sRGB
backlight9S5P WLED , 15K hours , With LED Driver
outline shapeSlim (PCBA Bent, T≤3.0mm)
used forLaptop
refresh rate60Hz
touchscreenWithout
signal typeeDP (4 Lanes) , eDP1.3 , HBR2 (5.4G/lane) , 40 pins Connector
voltage supply3.3V (Typ.)
max. ratingsStorage Temp.: -20 ~ 60 °C    Operating Temp.: 0 ~ 50 °C
