| Nama Wahi | N161HCA-EA3 |
| Waitohu | Innolux |
| Rahi | 16.1 |
| Taupānga | Laptop |
| Whakatau | 1920×1080 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | eDP |
| manufacturer | Innolux |
| model name | N161HCA-EA3 (CMN1604) |
| screen size | 16.1 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 1920(RGB)×1080 (FHD) 137PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 355.39 × 199.91 (H×V) |
| outline(mm) | 361.9 × 222.16 × 3.2 (H×V×D) |
| bezel area(mm) | - |
| treatment | Antiglare, Hard coating (3H) |
| luminance | 300 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| response | 11/9 (Typ.)(Tr/Td) ms |
| good view at | Symmetry |
| work mode | AAS, Normally Black, Transmissive |
| color depth | 16.7M 100% sRGB |
| backlight | WLED , 15K hours , With LED Driver |
| outline shape | Slim (PCBA Flat, T≤3.2mm) |
| used for | Laptop |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
