| Nama Wahi | N156BGA-EB3 |
| Waitohu | Innolux |
| Rahi | 15.6 |
| Taupānga | Laptop |
| Whakatau | 1366×768 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 600:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | eDP |
| brand | Innolux |
| model | N156BGA-EB3 (CMN15FD) |
| diagonal size | 15.6 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1366(RGB)×768 [WXGA] 100PPI |
| configuration | RGB Vertical Stripe |
| active area | 344.232(H)×193.536(V) mm |
| outline dim. | 350.73(H)×216.56(V) ×3.2(D) mm |
| bezel area | - |
| treatment | Glare (Haze 0%), Hard coating (3H) |
| luminance | 220 cd/m² (Typ.) |
| contrast ratio | 600:1 (Typ.) (TM) |
| view direction | 6 o'clock |
| response time | 3/7 (Typ.)(Tr/Td) |
| viewing angle | 45/45/20/45 (Typ.)(CR≥10) |
| operating mode | TN, Normally White, Transmissive |
| support color | 262K 45% NTSC |
| light source | WLED , 15K hours , With LED Driver |
| form style | Slim (PCBA Flat, T≤3.2mm) |
| designed for | Laptop |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
