Innolux N141C3-L04 Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com

N141C3-L04


Waitohu
Innolux
Rahi
14.1
Taupānga
NBPC
Whakatau
1440×900
Te tito
LCM
Tirohanga
220
CR
700:1
Nga Tae
262K
Whakamuri
CCFL
Atanga
LVDS
In Stock
17779
Whakatakotoranga

Nama Wahi N141C3-L04
WaitohuInnolux
Rahi14.1
TaupāngaNBPC
Whakatau1440×900
Te titoLCM
Tirohanga220
CR700:1
Nga Tae262K
WhakamuriCCFL
AtangaLVDS
panel brandCMO
panel modelN141C3-L04 2 Compatible model
panel type a-Si TFT-LCD , LCM
panel size14.1 inch
resolution1440(RGB)×900 , WXGA+
display modeTN, Normally White, Transmissive
active area303.48×189.675 mm
outline319.5×218×5.5 mm
shape styleWedge (PCBA Bent, Depth ≥5.2mm)
surfaceGlare (Haze 0%), Hard coating (3H)
brightness220 cd/m² (Typ.)
contrast ratio700:1 (Typ.)
display colors262K (6-bit), CIE193145%
response time5/11 (Typ.)(Tr/Td)
viewing angle45/45/20/45 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type1 pcsCCFLEmbedded (Inverter)
signal interfaceLVDS (2 ch, 6-bit), 30 pins
input voltage3.3V (Typ.)
applicationNBPC
