| Nama Wahi | N116BCA-EA1 |
| Waitohu | Innolux |
| Rahi | 11.6 |
| Taupānga | Laptop Industrial |
| Whakatau | 1366×768 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 262K |
| Whakamuri | 10S2P |
| Atanga | eDP |
| panel brand | Innolux |
| panel size | 11.6" |
| resolution | 1366(RGB)×768, WXGA, 135PPI |
| display area | 256.125(W)×144(H) mm |
| outline size | 278(W)×168(H) ×3(D) mm |
| brightness | 250 cd/m² (Typ.) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| best view on | Symmetry |
| display colors | 262K 45% NTSC |
| frequency | 60Hz |
| shape style | Slim (PCBA Flat, T≤3.2mm) |
| signal interface | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| panel model | N116BCA-EA1 (CMN1138) |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | - |
| surface | Antiglare, Hard coating (3H) |
| contrast ratio | 800:1 (Typ.) (TM) |
| display mode | AAS, Normally Black, Transmissive |
| response time | 14/11 (Typ.)(Tr/Td) |
| lamp type | 10S2P WLED , 15K hours , With LED Driver |
| touch screen | Without |
| application | Laptop Industrial |
| N116B6-L02 | Innolux | 11.6 | 1366×768 |
| N116B6-L04 | Innolux | 11.6 | 1366×768 |
| N116B6-L07 | Innolux | 11.6 | 1366×768 |
| N116BGE-EA2 | Innolux | 11.6 | 1366×768 |
| N116BGE-EB2 Rec.C3 | Innolux | 11.6 | 1366×768 |
| N116BGE-L11 | Innolux | 11.6 | 1366×768 |
| N116BGE-L32 | Innolux | 11.6 | 1366×768 |
| N116BGE-L41 | Innolux | 11.6 | 1366×768 |
| N116BGE-L42 | Innolux | 11.6 | 1366×768 |
| N116BGE-LB1 | Innolux | 11.6 | 1366×768 |
