| Nama Wahi | MV230FHB-N10 |
| Waitohu | BOE |
| Rahi | 23.0 |
| Taupānga | Desktop Monitor |
| Whakatau | 1920×1080 |
| Te tito | CELL , a-Si TFT-LC |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | No |
| Atanga | LVDS |
| manufacturer | BOE |
| model name | MV230FHB-N10 |
| screen size | 23.0 inch |
| screen type | CELL , a-Si TFT-LCD |
| pixel number | 1920(RGB)×1080 (FHD) 95PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 509.184 × 286.416 (H×V) |
| outline(mm) | - |
| bezel area(mm) | - |
| treatment | Antiglare (Haze 25%), Hard coating (3H) |
| luminance | 0 cd/m² |
| contrast ratio | 1000 : 1 (Min.) (TM) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| response | 14 (Typ.)(G to G) ms |
| good view at | Symmetry |
| work mode | ADS, Normally Black, Transmissive |
| glass thickness | 0.50+0.50 mm |
| transmissivity | - |
| color depth | 16.7M |
| backlight | No B/L |
| mass | - |
| used for | Desktop Monitor |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| voltage supply | 5.0V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
