Nama Wahi | MV215FHB-N70 |
Waitohu | BOE |
Rahi | 21.5 |
Taupānga | Desktop Monitor |
Whakatau | 1920×1080 |
Te tito | a-Si TFT-LCD , CELL |
Tirohanga | |
CR | 1000:1 |
Nga Tae | 16.7M |
Whakamuri | No |
Atanga | LVDS |
panel brand | BOE |
panel size | 21.5" |
resolution | 1920(RGB)×1080, FHD, 102PPI |
display area | 476.064(W)×267.786(H) mm |
outline size | 484.064(W)×278.976(H) ×1.34(D) mm |
brightness | 0 cd/m² |
viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
best view on | Symmetry |
glass depth | 0.50+0.50 mm |
display colors | 16.7M 77% NTSC |
frequency | 60Hz |
driver ic | COF Built-in 6 source chips |
panel weight | 426g (Typ.) |
signal interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
input voltage | 5.0V (Typ.) |
environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
panel model | MV215FHB-N70 |
panel type | a-Si TFT-LCD , CELL |
pixel format | RGB Vertical Stripe |
bezel opening | - |
surface | Antiglare (Haze 25%), Hard coating (3H) |
contrast ratio | 1000:1 (Typ.) (TM) |
display mode | ADS, Normally Black, Transmissive |
response time | 14 (Typ.)(G to G) |
transmissivity | 5.1% (Typ.)(with Polarizer) |
lamp type | No B/L |
touch screen | Without |
application | Desktop Monitor |
