| Nama Wahi | M238DAN01.1Q0 |
| Waitohu | AUO |
| Rahi | 23.8 |
| Taupānga | Desktop Monitor |
| Whakatau | 2560×1440 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | 20S4P |
| Atanga | LVDS |
| panel brand | AUO |
| panel model | M238DAN01.1Q0 |
| panel size | 23.8" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 2560(RGB)×1440, Quad-HD, 123PPI |
| pixel format | RGB Vertical Stripe |
| display area | 526.85(W)×296.35(H) mm |
| bezel opening | - |
| outline size | 534.74(W)×313.26(H) ×12.3(D) mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 300 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| display mode | AHVA, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 14 (Typ.)(G to G) |
| display colors | 16.7M 100% sRGB |
| lamp type | 20S4P WLED , 30K hours , Without Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | 2.20Kgs (Typ.) |
| application | Desktop Monitor |
| signal interface | LVDS (4 ch, 8-bit) , 92 pins Connector |
| input voltage | 5.0V (Typ.) |
| environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
