Nama Wahi | M201EW02 VG |
Waitohu | AUO |
Rahi | 20.1 |
Taupānga | DMPC |
Whakatau | 1680×1050 |
Te tito | LCM |
Tirohanga | |
CR | 1000:1 |
Nga Tae | 16.7M |
Whakamuri | |
Atanga | LVDS |
panel brand | AUO |
panel model | M201EW02 VG |
panel type | a-Si TFT-LCD , LCM |
panel size | 20.1 inch |
resolution | 1680(RGB)×1050 , WSXGA+ |
display mode | TN, Normally White, Transmissive |
active area | 433.44×270.9 mm |
surface | |
brightness | |
contrast ratio | 1000:1 (Typ.) |
display colors | 16.7M (6-bit + Hi-FRC) |
response time | |
viewing angle | |
frequency | 60Hz |
lamp type | |
signal interface | LVDS (2 ch, 8-bit) |
application | DMPC |
