Nama Wahi | M133NWF3 R2 |
Waitohu | IVO |
Rahi | 13.3 |
Taupānga | Laptop |
Whakatau | 1920×1080 |
Te tito | LCM , a-Si TFT-LCD |
Tirohanga | - |
CR | 600:1 |
Nga Tae | 16.7M |
Whakamuri | WLED |
Atanga | eDP |
manufacturer | IVO |
screen size | 13.3 inch |
pixel number | 1920(RGB)×1080 (FHD) 166PPI |
active area(mm) | 293.76 × 165.24 (H×V) |
luminance | - |
viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
good view at | Symmetry |
color depth | 16.7M 72% NTSC |
outline shape | Slim (PCBA Flat, T≤3.2mm) |
refresh rate | - |
signal type | eDP (4 Lanes) , eDP1.3 Connector |
voltage supply | 3.3V (Typ.) |
max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
model name | M133NWF3 R2 |
screen type | LCM , a-Si TFT-LCD |
arrangement | RGB Vertical Stripe |
outline(mm) | - |
contrast ratio | 600 : 1 (Typ.) (TM) |
response | 25 (Typ.)(Tr+Td) ms |
work mode | IPS, Normally Black, Transmissive |
backlight | WLED , 15K hours , With LED Driver |
used for | Laptop |
touchscreen | Without |
