| Nama Wahi | M102AWF2 R3 |
| Waitohu | IVO |
| Rahi | 10.3 |
| Taupānga | Automotive Display |
| Whakatau | 1920×720 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| brand | IVO |
| model | M102AWF2 R3 |
| diagonal size | 10.3 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1920(RGB)×720 200PPI |
| configuration | RGB Vertical Stripe |
| active area | 243.65(H)×91.37(V) mm |
| outline dim. | 261.14(H)×109.3(V) ×15.8(D) mm |
| bezel area | 245.65(H)×94.37(V) mm |
| treatment | Hard coating (3H) |
| luminance | 800 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 20 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| operating mode | IPS, Normally Black, Transmissive |
| support color | 16.7M 75% NTSC |
| light source | WLED [8S3P] , 10K hours , W/O Driver |
| weight | 350g (Max.) |
| designed for | Automotive Display |
| frame rate | 55Hz |
| touch panel | Without |
| interface type | LVDS (2 ch, 8-bit) , 50 pins Connector |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 3.0G (29.4 m/s²) |
