| Nama Wahi | M102AWF2 R2 |
| Waitohu | IVO |
| Rahi | 10.3 |
| Taupānga | Automotive Display |
| Whakatau | 1920×720 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | 8S3P |
| Atanga | LVDS |
| panel brand | IVO |
| panel model | M102AWF2 R2 |
| panel size | 10.3" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 1920(RGB)×720, 200PPI |
| pixel format | RGB Vertical Stripe |
| display area | 243.65(W)×91.37(H) mm |
| bezel opening | 245.65(W)×93.66(H) mm |
| outline size | 262.04(W)×110.3(H) ×16(D) mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 800 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| display mode | IPS, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 20 (Typ.)(Tr+Td) |
| display colors | 16.7M 75% NTSC |
| lamp type | 8S3P WLED , 10K hours , Without Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | 380g (Max.) |
| application | Automotive Display |
| signal interface | LVDS (2 ch, 8-bit) , 50 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 3.0G (29.4 m/s²) |
