LTN133AT23-001

LTN133AT23-001
LTN133AT23-001
LTN133AT23-001 thumb LTN133AT23-001 thumb
Waitohu
Samsung
Rahi
13.3
Taupānga
NBPC
Whakatau
1366×768
Te tito
LCM
Tirohanga
300
CR
220:1
Nga Tae
262K
Whakamuri
WLED
Atanga
LVDS
In Stock
18081
Whakatakotoranga

Nama Wahi LTN133AT23-001
WaitohuSamsung
Rahi13.3
TaupāngaNBPC
Whakatau1366×768
Te titoLCM
Tirohanga300
CR220:1
Nga Tae262K
WhakamuriWLED
AtangaLVDS
panel brandSAMSUNG
panel modelLTN133AT23-001
panel type a-Si TFT-LCD , LCM
panel size13.3 inch
resolution1366(RGB)×768 , WXGA
display modeTN, Normally White, Transmissive
active area293.42×164.97 mm
surfaceAntiglare (Haze 25%)
brightness300 cd/m² (Min.)
contrast ratio220:1 (Typ.)
display colors262K (6-bit), CIE193145%
response time16 (Typ.)(Tr+Td)
viewing angle45/45/15/35 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type8S4PWLEDEmbedded (LED Driver)
signal interfaceLVDS (1 ch, 6-bit), 40 pins
input voltage3.3V (Typ.)
applicationNBPC
