| Nama Wahi | LSM315DP01-M01 |
| Waitohu | SAMSUNG |
| Rahi | 32.0 |
| Taupānga | Desktop Monitor Gami |
| Whakatau | 2560×1440 |
| Te tito | a-Si TFT-LCD , CELL |
| Tirohanga | |
| CR | 3000:1 |
| Nga Tae | 16.7M |
| Whakamuri | No |
| Atanga | eDP |
| brand | SAMSUNG |
| diagonal size | 32.0 inch |
| pixel format | 2560(RGB)×1440 [Quad-HD] 93PPI |
| active area | 697.344(H)×392.256(V) mm |
| bezel area | - |
| luminance | 0 cd/m² |
| view direction | Symmetry |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| plate thickness | 0.40+0.40 mm |
| support color | 16.7M 70% NTSC |
| weight | 900g (Typ.) |
| frame rate | 144Hz |
| d-ic detail | COF Built-in 8 source chips |
| interface type | eDP (4 Lanes) , HBR2 (5.4G/lane) , 51 pins Connector |
| power supply | 12.0V (Typ.) |
| environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | LSM315DP01-M01 |
| type | a-Si TFT-LCD , CELL |
| configuration | RGB Vertical Stripe |
| outline dim. | 708.944(H)×405.731(V) ×1.11(D) mm |
| treatment | Antiglare (Haze 25%) |
| contrast ratio | 3000:1 (Typ.) (TM) |
| response time | 22 (Typ.)(G to G) |
| operating mode | PVA, Normally Black, Transmissive |
| transmittance | 3.0% (Typ.)(with Polarizer) |
| light source | No B/L |
| designed for | Desktop Monitor Gaming |
| touch panel | Without |
