| Nama Wahi | LSC480HN10 |
| Waitohu | SAMSUNG |
| Rahi | 48 |
| Taupānga | TV Sets |
| Whakatau | 1920×1080 |
| Te tito | a-Si TFT-LCD, CELL |
| Tirohanga | |
| CR | 4000:1 |
| Nga Tae | 1.07B |
| Whakamuri | No |
| Atanga | LVDS |
| brand | SAMSUNG |
| model | LSC480HN10 |
| diagonal size | 48 inch |
| type | a-Si TFT-LCD, CELL |
| pixel format | 1920×1080(RGB) [FHD] 46PPI |
| configuration | RGB Horizontal Stripe |
| active area | 1054.08(H)×592.92(V) mm |
| outline dim. | 1068.08(H)×608.92(V) ×1.4(D) mm |
| bezel area | - |
| treatment | Antiglare, Hard coating (2H) |
| luminance | 0 cd/m² |
| contrast ratio | 4000:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 8 (Typ.)(G to G) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| operating mode | SVA, Normally Black, Transmissive |
| plate thickness | 0.50+0.50 mm |
| transmittance | 6.6% (Typ.)(with Polarizer) |
| support color | 1.07B 68% NTSC |
| light source | No B/L |
| weight | 1.90Kgs (Typ.) |
| designed for | TV Sets |
| frame rate | 60Hz |
| touch panel | Without |
| d-ic detail | COF Built-in 2 source chips |
| interface type | LVDS (2 ch, 10-bit) , 51 pins Connector |
| power supply | 12.0V (Typ.) |
| environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C |
