| Nama Wahi | LSC480HN08-W |
| Waitohu | SAMSUNG |
| Rahi | 48 |
| Taupānga | TV Sets |
| Whakatau | 1920×1080 |
| Te tito | CELL, a-Si TFT-LCD |
| Tirohanga | |
| CR | 5000:1 |
| Nga Tae | 1.07B |
| Whakamuri | No |
| Atanga | LVDS |
| manufacturer | SAMSUNG |
| model name | LSC480HN08-W |
| screen size | 48 inch |
| screen type | CELL, a-Si TFT-LCD |
| pixel number | 1920×1080(RGB) (FHD) 46PPI |
| arrangement | RGB Horizontal Stripe |
| active area(mm) | 1054.08 × 592.92 (H×V) |
| outline(mm) | 1068.08 × 608.92 × 1.4 (H×V×D) |
| bezel area(mm) | - |
| treatment | Antiglare (Haze 2.3%), Hard coating (2H) |
| luminance | 0 cd/m² |
| contrast ratio | 5000 : 1 (Typ.) (TM) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| response | 8 (Typ.)(G to G) ms |
| good view at | Symmetry |
| work mode | SVA, Normally Black, Transmissive |
| glass thickness | 0.50+0.50 mm |
| transmissivity | 6.6% (Typ.)(with Polarizer) |
| color depth | 1.07B 68% NTSC |
| backlight | No B/L |
| mass | 1.90Kgs (Typ.) |
| used for | TV Sets |
| refresh rate | 60Hz |
| touchscreen | Without |
| driver ic list | Built-in COF 3 source chips |
| signal type | LVDS (2 ch, 10-bit) , Connector 51 pins |
| voltage supply | 12.0V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 65 °C Operating Temp.: 0 ~ 50 °C |
