| Nama Wahi | LSC320AN09-H |
| Waitohu | SAMSUNG |
| Rahi | 32.0 |
| Taupānga | TV Sets |
| Whakatau | 1366×768 |
| Te tito | a-Si TFT-LCD , CELL |
| Tirohanga | |
| CR | 4000:1 |
| Nga Tae | 16.7M |
| Whakamuri | No |
| Atanga | LVDS |
| panel brand | SAMSUNG |
| panel size | 32.0" |
| resolution | 1366×768(RGB), WXGA, 49PPI |
| display area | 697.685(W)×392.256(H) mm |
| outline size | 713(W)×410.5(H) ×1.3(D) mm |
| brightness | 0 cd/m² |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| best view on | Symmetry |
| glass depth | 0.50+0.50 mm |
| display colors | 16.7M 69% NTSC |
| frequency | 60Hz |
| driver ic | COF Built-in 1 source chips |
| panel weight | 800g (Typ.) |
| signal interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| input voltage | 12.0V (Typ.) |
| environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 65 °C |
| panel model | LSC320AN09-H |
| panel type | a-Si TFT-LCD , CELL |
| pixel format | RGB Horizontal Stripe |
| bezel opening | - |
| surface | Antiglare (Haze 2%), Hard coating (2H) |
| contrast ratio | 4000:1 (Typ.) (TM) |
| display mode | SVA, Normally Black, Transmissive |
| response time | 20 (Typ.)(G to G) |
| transmissivity | 6.9% (Typ.)(with Polarizer) |
| lamp type | No B/L |
| touch screen | Without |
| application | TV Sets |
