| Nama Wahi | LS124M5LZ01 |
| Waitohu | Sharp |
| Rahi | 12.4 |
| Taupānga | Automotive Display |
| Whakatau | 1920×720 |
| Te tito | LCM, Oxide TFT-LCD |
| Tirohanga | |
| CR | 1500:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| manufacturer | Sharp |
| model name | LS124M5LZ01 |
| screen size | 12.4 inch |
| screen type | LCM, Oxide TFT-LCD |
| pixel number | 1920(RGB)×720 165PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 295.2 × 110.7 (H×V) |
| outline(mm) | 301.3 × 125.7 × 14.85 (H×V×D) |
| bezel area(mm) | 296.6 × 112.1 (H×V) |
| treatment | Antiglare, Antireflection |
| luminance | 1000 cd/m² (Typ.) |
| contrast ratio | 1500 : 1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| response | 12/12 (Typ.)(Tr/Td) ms |
| good view at | Symmetry |
| work mode | New Mode, Normally Black, Transmissive |
| color depth | 16.7M 74% NTSC |
| backlight | WLED , 10K hours , With LED Driver |
| mass | 620g (Typ.) |
| used for | Automotive Display |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (2 ch, 8-bit) , Connector 68 pins |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
