| Nama Wahi | LS055R3SX01 |
| Waitohu | Sharp |
| Rahi | 5.5 |
| Taupānga | Mobile Phone |
| Whakatau | 1536×2560 |
| Te tito | CG-Silicon , LCM |
| Tirohanga | |
| CR | 1280:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | MIPI |
| brand | Sharp |
| diagonal size | 5.5 inch |
| pixel format | 1536(RGB)×2560 546PPI |
| active area | 71.424(H)×119.04(V) mm |
| luminance | 460 cd/m² (Typ.) |
| view direction | Symmetry |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| support color | 16.7M 70% NTSC |
| weight | 21.1g |
| frame rate | 60Hz |
| interface type | MIPI (4 data lanes) , 32 pins Connector |
| power supply | 1.8/5.5/-5.5V (Typ.)(IOVDD/VSP/VSN) |
| environment | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| model | LS055R3SX01 |
| type | CG-Silicon , LCM |
| configuration | RGB Vertical Stripe |
| outline dim. | 73.824(H)×126.44(V) ×1.4(D) mm |
| contrast ratio | 1280:1 (Typ.) (TM) |
| response time | 30 (Typ.)(Tr+Td) |
| operating mode | New Mode2, Normally Black, Transmissive |
| light source | WLED [8S2P] , W/O Driver |
| designed for | Mobile Phone |
| touch panel | Without |
