SHARP LS037V7DW03B Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com

LS037V7DW03B


Waitohu
SHARP
Rahi
3.7
Taupānga
HHP
Whakatau
480×640
Te tito
LCM
Tirohanga
200
CR
200:1
Nga Tae
262K
Whakamuri
WLED
Atanga
TTL
In Stock
4660
Whakatakotoranga

Nama Wahi LS037V7DW03B
WaitohuSHARP
Rahi3.7
TaupāngaHHP
Whakatau480×640
Te titoLCM
Tirohanga200
CR200:1
Nga Tae262K
WhakamuriWLED
AtangaTTL
panel brandSHARP
panel modelLS037V7DW03B 2 Compatible model
panel type CG-Silicon , LCM
panel size3.7 inch
resolution480(RGB)×640 , VGA
display modeASV, Normally Black, Transflective
active area56.16×74.88 mm
outline65×89.2 mm
surface
brightness200 cd/m² (Typ.)
contrast ratio200:1 (Typ.)(Transmissive)2:1 (Typ.)(Reflective)
display colors262K (6-bit), CIE193135%
response time15/20 (Typ.)(Tr/Td)
viewing angle80/80/80/80 (Typ.)(CR≥5)(L/R/U/D)
lamp type7S1PWLEDWithout Driver
signal interfaceParallel RGB (1 ch, 6-bit), 51 pins
input voltage3.3V (Typ.)(VSHD)
applicationHHP
Tauira Whanau
LS037V3DX01 SHARP 3.7 640×480
LS037V3DX02 SHARP 3.7
LS037V7DD05 SHARP 3.7 480×640
LS037V7DD06 SHARP 3.7 480×640
LS037V7DD06R SHARP 3.7 480×640
LS037V7DW01 SHARP 3.7 480×640
LS037V7DW02 SHARP 3.7 480×640
LS037V7DW03 SHARP 3.7 480×640
LS037V7DW03A SHARP 3.7 480×640
LS037V7DW03B SHARP 3.7 480×640
