| Nama Wahi | LS012B7DD06 |
| Waitohu | Sharp |
| Rahi | 1.2 |
| Taupānga | Wearable Round Displ |
| Whakatau | 240×240 |
| Te tito | LCM , CG-Silicon |
| Tirohanga | |
| CR | 25:1 |
| Nga Tae | 64 |
| Whakamuri | No |
| Atanga | Parallel |
| manufacturer | Sharp |
| screen size | 1.2 inch |
| pixel number | 240(RGB)×240 201PPI |
| active area(mm) | 30.24 × 30.24 (H×V) |
| bezel area(mm) | - |
| luminance | - |
| viewing angle | 60/60/60/60 (Typ.)(CR≥2) |
| good view at | - |
| color depth | 64 18% NTSC |
| mass | 1.60g (Max.) |
| refresh rate | 30Hz |
| signal type | Parallel Data (1ch, 6-bit) , 21 pins FPC |
| voltage supply | 3.2/5.0V (Typ.)(VDD1/VDD2) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| model name | LS012B7DD06 |
| screen type | LCM , CG-Silicon |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 33.04 × 33.94 (H×V×D) |
| treatment | Hard coating (3H) |
| contrast ratio | 25:1 (Typ.) (RF) |
| response | 30/20 (Typ.)(Tr/Td) ms |
| work mode | ASV, Normally Black, Transflective |
| backlight | No B/L |
| used for | Wearable Round Display |
| touchscreen | Without |
