| Nama Wahi | LQ9D011 |
| Waitohu | SHARP |
| Rahi | 8.4 |
| Taupānga | IA |
| Whakatau | 640×480 |
| Te tito | LCM |
| Tirohanga | 70 |
| CR | 60:1 |
| Nga Tae | 512 |
| Whakamuri | CCFL |
| Atanga | TTL |
| panel brand | SHARP |
| panel model | LQ9D011 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.4 inch |
| resolution | 640(RGB)×480 , VGA |
| display mode | TN, Normally White, Transmissive |
| active area | 170.88×129.6 mm |
| outline | 243.5×180 mm |
| surface | Antiglare, Hard coating (2H) |
| brightness | 70 cd/m² (Typ.) |
| contrast ratio | 60:1 (Typ.) |
| display colors | 512 (3-bit) |
| response time | 30/50 (Typ.)(Tr/Td) |
| viewing angle | 45/45/10/30 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 2 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 3-bit), 21 pins |
| input voltage | 5.0V (Typ.)(VCC) |
| application | IA |
