| Nama Wahi | LQ800D3HA01 |
| Waitohu | Sharp |
| Rahi | 80 |
| Taupānga | TV Sets |
| Whakatau | 1920×1080 |
| Te tito | a-Si TFT-LCD, CELL |
| Tirohanga | |
| CR | 5000:1 |
| Nga Tae | 1.07B |
| Whakamuri | No |
| Atanga | LVDS |
| panel brand | Sharp |
| panel model | LQ800D3HA01 |
| panel size | 80" |
| panel type | a-Si TFT-LCD, CELL |
| resolution | 1920(RGB)×1080, FHD, 27PPI |
| pixel format | RGB Vertical Stripe |
| display area | 1771.2(W)×996.3(H) mm |
| bezel opening | - |
| outline size | 1802.6(W)×1026.9(H) ×1.7(D) mm |
| surface | Antiglare (Haze 3%), Hard coating (2H) |
| brightness | 0 cd/m² |
| contrast ratio | 5000:1 (Typ.) (TM) |
| viewing angle | 88/88/88/88 (Typ.)(CR≥10) |
| display mode | ASV, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 4 (Typ.)(G to G) |
| glass depth | - |
| transmissivity | 6.51% (Typ.)(with Polarizer) |
| display colors | 1.07B 73% NTSC |
| lamp type | No B/L |
| frequency | 120Hz |
| touch screen | Without |
| driver ic | COF Built-in 16 source + 10 gate chips |
| panel weight | 7.80g (Typ.) |
| application | TV Sets |
| signal interface | LVDS (4 ch, 10-bit) , 92 pins Connector |
| input voltage | 12.0V (Typ.) |
| environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C |
