| Nama Wahi | LQ173D1JW33 |
| Waitohu | Sharp |
| Rahi | 17.3 |
| Taupānga | Laptop |
| Whakatau | 3840×2160 |
| Te tito | Oxide TFT-LCD , LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | eDP |
| panel brand | Sharp |
| panel size | 17.3" |
| resolution | 3840(RGB)×2160, UHD, 255PPI |
| display area | 382.12(W)×214.94(H) mm |
| outline size | 393.69(W)×252.1(H) ×4(D) mm |
| brightness | 350 cd/m² (Typ.) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| best view on | Symmetry |
| display colors | 16.7M 100% Adobe RGB |
| frequency | 60Hz |
| shape style | Flat (PCBA Flat, T3.4~4.0mm) |
| signal interface | eDP (4 Lanes) , eDP1.3 , HBR2 (5.4G/lane) , 40 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| panel model | LQ173D1JW33 (SHP145A) |
| panel type | Oxide TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | - |
| surface | Antiglare (Haze 45%), Hard coating (3H) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| display mode | IPS, Normally Black, Transmissive |
| response time | 30 (Typ.)(Tr+Td) |
| lamp type | WLED , 12K hours , With LED Driver |
| touch screen | Without |
| application | Laptop |
