Nama Wahi | LQ140M1JX41 |
Waitohu | Sharp |
Rahi | 14.0 |
Taupānga | Laptop |
Whakatau | 1920×1080 |
Te tito | LCM, Oxide TFT-LCD |
Tirohanga | |
CR | 1500:1 |
Nga Tae | 16.7M |
Whakamuri | WLED |
Atanga | eDP |
manufacturer | Sharp |
model name | LQ140M1JX41 |
screen size | 14.0 inch |
screen type | LCM, Oxide TFT-LCD |
pixel number | 1920(RGB)×1080 (FHD) 157PPI |
arrangement | RGB Vertical Stripe |
active area(mm) | 309.312 × 173.988 (H×V) |
outline(mm) | - |
bezel area(mm) | - |
treatment | Glare (Haze 0%) |
luminance | - |
contrast ratio | 1500 : 1 (Typ.) (TM) |
viewing angle | 89/89/89/89 (Min.)(CR≥10) |
response | 30 (Typ.)(Tr+Td) ms |
good view at | Symmetry |
work mode | New Mode2, Normally Black, Transmissive |
color depth | 16.7M |
backlight | WLED , 15K hours |
outline shape | Slim (PCBA Flat, T≤3.2mm) |
used for | Laptop |
refresh rate | 60Hz |
touchscreen | Without |
signal type | eDP (2 Lanes) , Connector |
max. ratings | Storage Temp.: -25 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
