| Nama Wahi | LQ050A5AG03 |
| Waitohu | Sharp |
| Rahi | 5.0 |
| Taupānga | Automotive Display |
| Whakatau | 320×234 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 60:1 |
| Nga Tae | Full |
| Whakamuri | 1 |
| Atanga | Analog |
| manufacturer | Sharp |
| model name | LQ050A5AG03 |
| screen size | 5.0 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 320(RGB)×234 79PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 102.124 × 74.763 (H×V) |
| outline(mm) | 126.8 × 89.9 × 16.5 (H×V×D) |
| bezel area(mm) | - |
| treatment | Antireflection |
| luminance | 320 cd/m² (Typ.) |
| contrast ratio | 60 : 1 (Typ.) (TM) |
| viewing angle | 65/65/40/65 (Typ.)(CR≥5) |
| response | 30/50 (Typ.)(Tr/Td) ms |
| good view at | - |
| work mode | TN, Normally White, Transmissive |
| color depth | Full color |
| backlight | 1 pcs CCFL , 10K hours , No Driver |
| mass | 180g (Max.) |
| used for | Automotive Display |
| refresh rate | - |
| touchscreen | Without |
| signal type | Analog RGB , Connector 22 pins |
| voltage supply | 8.0/-5.0V (Typ.)(VSH/VSL) |
| max. ratings | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
