| Nama Wahi | LQ042Q1DW40P |
| Waitohu | Sharp |
| Rahi | 4.2 |
| Taupānga | Portable Navigation |
| Whakatau | 320×320 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | Parallel |
| brand | Sharp |
| model | LQ042Q1DW40P |
| diagonal size | 4.2 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 320(RGB)×320 [QVGA] 108PPI |
| configuration | RGB Vertical Stripe |
| active area | 84.96(H)×63.72(V) mm |
| outline dim. | 96.8(H)×71.5(V) mm |
| bezel area | - |
| treatment | Antiglare, Hard coating (3H) |
| luminance | 180 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) (TM) |
| view direction | - |
| response time | 35/35 (Typ.)(Tr/Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| operating mode | TN, Normally White, Transmissive |
| support color | 16.7M |
| light source | WLED [6S1P] , W/O Driver |
| weight | 39.0g (Typ.) |
| designed for | Portable Navigation |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | Parallel RGB (1 ch, 8-bit) , 53 pins FPC |
| power supply | 1.8/5.0/-5.0/14.5/-14.5V (Typ.)(VSHD/VSHA/GVSS/VGH/VGL) |
| environment | Operating Temperature: 0 ~ 40 °C ; Storage Temperature: -25 ~ 60 °C |
