| Nama Wahi | LPM089A128A |
| Waitohu | JDI |
| Rahi | 8.9 |
| Taupānga | Pad & Tablet |
| Whakatau | 1536×2048 |
| Te tito | LTPS TFT-LCD, LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | MIPI |
| brand | JDI |
| model | LPM089A128A |
| diagonal size | 8.9 inch |
| type | LTPS TFT-LCD, LCM |
| pixel format | 1536(RGB)×2048 [QXGA] 288PPI |
| configuration | RGB Vertical Stripe |
| active area | 135.245(H)×180.326(V) mm |
| outline dim. | 140.85(H)×190.75(V) mm |
| bezel area | - |
| treatment | Hard coating (3H) |
| luminance | 420 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 30 (Max.)(Tr+Tf) |
| viewing angle | 80/80/80/80 (Min.)(CR≥10) |
| operating mode | IPS, Normally Black, Transmissive |
| support color | 16.7M 71% NTSC |
| light source | WLED [7S4P] , W/O Driver |
| weight | 90.26g |
| designed for | Pad & Tablet |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | MIPI (2 ch, 4 data lanes) , 51 pins Connector |
| power supply | 1.8/3.8V (Typ.)(IOVDD/AVDD) |
| environment | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
