| Nama Wahi | LP173WF5-SPZ1 |
| Waitohu | LG Display |
| Rahi | 17.3 |
| Taupānga | Laptop |
| Whakatau | 1920×1080 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.2M |
| Whakamuri | WLED |
| Atanga | eDP |
| panel brand | LG Display |
| panel size | 17.3" |
| resolution | 1920(RGB)×1080, FHD, 127PPI |
| display area | 381.888(W)×214.812(H) mm |
| outline size | 389.89(W)×238.31(H) ×3.5(D) mm |
| brightness | 250 cd/m² (Typ.) |
| viewing angle | 80/80/80/80 (MIn.)(CR≥10) |
| best view on | Symmetry |
| display colors | 16.2M 72% NTSC |
| frequency | 60Hz |
| shape style | Slim (PCBA Flat, T≤3.2mm) |
| signal interface | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| panel model | LP173WF5-SPZ1 (LGD063B) |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | - |
| surface | Antiglare, Hard coating (3H) |
| contrast ratio | 800:1 (Typ.) (TM) |
| display mode | IPS, Normally Black, Transmissive |
| response time | 25 (Typ.)(Tr+Td) |
| lamp type | WLED , 15K hours , With LED Driver |
| touch screen | Without |
| application | Laptop |
