| Nama Wahi | LP156WF9-SPN1 |
| Waitohu | LG Display |
| Rahi | 15.6 |
| Taupānga | Laptop |
| Whakatau | 1920×1080 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | eDP |
| panel brand | LG Display |
| panel size | 15.6" |
| resolution | 1920(RGB)×1080, FHD, 141PPI |
| display area | 344.16(W)×193.59(H) mm |
| outline size | 350.66(W)×205.8(H) ×4.4(D) mm |
| brightness | 300 cd/m² (Typ.) |
| viewing angle | 80/80/80/80 (Min.)(CR≥10) |
| best view on | Symmetry |
| display colors | 262K 99% sRGB |
| frequency | 60Hz |
| shape style | Slim (PCBA Bent, T≤3.0mm) |
| signal interface | eDP (2 Lanes) , eDP1.3 , HBR1 (2.7G/lane) , 30 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| panel model | LP156WF9-SPN1 (LGD05A8) |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | - |
| surface | Glare (Haze 0%) |
| contrast ratio | 800:1 (Typ.) (TM) |
| display mode | IPS, Normally Black, Transmissive |
| response time | 25 (Typ.)(Tr+Td) |
| lamp type | WLED , 12K hours , With LED Driver |
| touch screen | Without |
| application | Laptop |
