| Nama Wahi | LP156UD3-SPB1 |
| Waitohu | LG Display |
| Rahi | 15.6 |
| Taupānga | Laptop Industrial |
| Whakatau | 3840×2160 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 1700:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | eDP |
| manufacturer | LG Display |
| model name | LP156UD3-SPB1 |
| screen size | 15.6 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 3840(RGB)×2160 (UHD) 283PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 344.218 × 193.622 (H×V) |
| outline(mm) | 349.92 × 215.87 × 2.6 (H×V×D) |
| bezel area(mm) | - |
| treatment | Antiglare, Hard coating (3H) |
| luminance | 600 cd/m² (Typ.) |
| contrast ratio | 1700 : 1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| response | 30 (Typ.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | IPS, Normally Black, Transmissive |
| color depth | 16.7M 100% DCI-P3 |
| backlight | WLED , 12K hours , With LED Driver |
| outline shape | Slim (PCBA Flat, T≤3.2mm) |
| used for | Laptop Industrial |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | eDP (4 Lanes) , eDP1.4 , HBR2 (5.4G/lane) , 40 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
