| Nama Wahi | LP116WH7-SPC2 |
| Waitohu | LG Display |
| Rahi | 11.6 |
| Taupānga | Laptop |
| Whakatau | 1366×768 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 600:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | eDP |
| panel brand | LG Display |
| panel model | LP116WH7-SPC2 (LGD04DC) |
| panel size | 11.6" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 1366(RGB)×768, WXGA, 135PPI |
| pixel format | RGB Vertical Stripe |
| display area | 256.125(W)×144(H) mm |
| bezel opening | 259.25(W)×147.8(H) mm |
| outline size | 268.35(W)×157.35(H) ×4.8(D) mm |
| surface | Glare (Haze 0%), Hard coating (3H) |
| brightness | 220 cd/m² (Typ.) |
| contrast ratio | 600:1 (Typ.) (TM) |
| viewing angle | 80/80/80/80 (Min.)(CR≥10) |
| display mode | IPS, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 35 (Typ.)(Tr+Td) |
| display colors | 262K 49% NTSC |
| lamp type | WLED , 15K hours , With LED Driver |
| frequency | 60Hz |
| touch screen | Without |
| shape style | Slim (PCBA Bent, T≤3.0mm) |
| application | Laptop |
| signal interface | eDP (2 Lanes) , HBR1 (2.7G/lane) , 30 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
