LP101WH1-TLP1

LP101WH1-TLP1
LP101WH1-TLP1
LP101WH1-TLP1
LP101WH1-TLP1 thumb LP101WH1-TLP1 thumb LP101WH1-TLP1 thumb
Waitohu
LG Display
Rahi
10.1
Taupānga
NBPC
Whakatau
1366×768
Te tito
LCM
Tirohanga
200
CR
400:1
Nga Tae
262K
Whakamuri
WLED
Atanga
LVDS
In Stock
940
Whakatakotoranga

Nama Wahi LP101WH1-TLP1
WaitohuLG Display
Rahi10.1
TaupāngaNBPC
Whakatau1366×768
Te titoLCM
Tirohanga200
CR400:1
Nga Tae262K
WhakamuriWLED
AtangaLVDS
panel brandLG Display
panel modelLP101WH1-TLP1
panel type a-Si TFT-LCD , LCM
panel size10.1 inch
resolution1366(RGB)×768 , WXGA
display modeTN, Normally White, Transmissive
active area222.73×125.22 mm
outline235×143×5.2 mm
shape styleWedge (PCBA Bent, Depth ≥5.2mm)
surfaceAntiglare
brightness200 cd/m² (Typ.)
contrast ratio400:1 (Min.)
display colors262K (6-bit)
response time16 (Typ.)(Tr+Td)
viewing angle30/30/10/20 (Min.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp typeWLEDEmbedded (LED Driver)
signal interfaceLVDS (1 ch, 6-bit), 40 pins
input voltage3.3V (Typ.)
applicationNBPC
