| Nama Wahi | LMS340KC01-001 |
| Waitohu | Samsung |
| Rahi | 3.4 |
| Taupānga | MPH |
| Whakatau | 720×480 |
| Te tito | LCM |
| Tirohanga | 300 |
| CR | 500:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | SAMSUNG |
| panel model | LMS340KC01-001 |
| panel type | LTPS TFT-LCD , LCM |
| panel size | 3.4 inch |
| resolution | 720(RGB)×480 |
| display mode | PVA, Normally Black, Transmissive |
| active area | 71.82×47.88 mm |
| outline | 82.22×53.88×21 mm |
| surface | Hard coating (2H) |
| brightness | 300 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | 30 (Typ.)(Tr+Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 45 pins |
| input voltage | 1.8/2.8V (Typ.)(VDD1/VDD2) |
| application | MPH |
