| Nama Wahi | LM156LF5L06 |
| Waitohu | PANDA |
| Rahi | 15.6 |
| Taupānga | Laptop |
| Whakatau | 1920×1080 |
| Te tito | LCM , Oxide TFT-LC |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | eDP |
| manufacturer | PANDA |
| screen size | 15.6 inch |
| pixel number | 1920(RGB)×1080 (FHD) 141PPI |
| active area(mm) | 344.16 × 193.59 (H×V) |
| bezel area(mm) | - |
| luminance | 250 cd/m² (Typ.) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| good view at | Symmetry |
| color depth | 16.7M 47% NTSC |
| outline shape | Slim (PCBA Flat, T≤3.2mm) |
| refresh rate | 60Hz |
| signal type | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| model name | LM156LF5L06 (NCP0046) |
| screen type | LCM , Oxide TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 350.66 × 216.15 × 3.2 (H×V×D) |
| treatment | Antiglare, Hard coating (3H) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| response | 25 (Typ.)(Tr+Tf) ms |
| work mode | FFS, Normally Black, Transmissive |
| backlight | WLED , With LED Driver |
| used for | Laptop |
| touchscreen | Without |
