Nama Wahi | LM133LF9L02 |
Waitohu | PANDA |
Rahi | 13.3 |
Taupānga | Laptop |
Whakatau | 1920×1080 |
Te tito | Oxide TFT-LCD , LCM |
Tirohanga | |
CR | 1000:1 |
Nga Tae | 16.7M |
Whakamuri | WLED |
Atanga | eDP |
brand | PANDA |
diagonal size | 13.3 inch |
pixel format | 1920(RGB)×1080 [FHD] 166PPI |
active area | 293.76(H)×165.24(V) mm |
bezel area | - |
luminance | 300 cd/m² (Typ.) |
view direction | Symmetry |
viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
support color | 16.7M 100% sRGB |
form style | Slim (PCBA Bent, T≤3.0mm) |
frame rate | 60Hz |
interface type | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
power supply | 3.3V (Typ.) |
environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
model | LM133LF9L02 |
type | Oxide TFT-LCD , LCM |
configuration | RGB Vertical Stripe |
outline dim. | 300.26(H)×177.35(V) ×4.35(D) mm |
treatment | Antiglare |
contrast ratio | 1000:1 (Typ.) (TM) |
response time | 25 (Typ.)(Tr+Tf) |
operating mode | FFS, Normally Black, Transmissive |
light source | WLED , 15K hours , With LED Driver |
designed for | Laptop |
touch panel | Without |
