| Nama Wahi | LM116LF3L02 |
| Waitohu | PANDA |
| Rahi | 11.6 |
| Taupānga | Pad & Tablet |
| Whakatau | 1920×1080 |
| Te tito | LCM , Oxide TFT-LC |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | eDP |
| manufacturer | PANDA |
| model name | LM116LF3L02 (NCP0000) |
| screen size | 11.6 inch |
| screen type | LCM , Oxide TFT-LCD |
| pixel number | 1920(RGB)×1080 (FHD) 190PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 256.32 × 144.18 (H×V) |
| outline(mm) | 268 × 168 × 3 (H×V×D) |
| bezel area(mm) | - |
| treatment | Antiglare, Hard coating (3H) |
| luminance | 300 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| response | 25 (Typ.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | FFS, Normally Black, Transmissive |
| color depth | 16.7M 100% sRGB |
| backlight | WLED , 15K hours , With LED Driver |
| mass | 215g (Max.) |
| used for | Pad & Tablet |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | eDP (2 Lanes) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
