| Nama Wahi | LD860DBN-UJA2 |
| Waitohu | LG Display |
| Rahi | 86 |
| Taupānga | Digital Signage Outd |
| Whakatau | 3840×600 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1100:1 |
| Nga Tae | 1.07B |
| Whakamuri | WLED |
| Atanga | V-by-One |
| brand | LG Display |
| model | LD860DBN-UJA2 |
| diagonal size | 86 inch (Native bar) |
| type | a-Si TFT-LCD, LCM |
| pixel format | 3840(RGB)×600 45PPI |
| configuration | RGB Vertical Stripe |
| active area | 2148.48(H)×335.7(V) mm |
| outline dim. | 2158.3(H)×348.5(V) ×82.2(D) mm |
| bezel area | 2149.5(H)×336.7(V) mm |
| treatment | Antiglare (Haze 10%), Hard coating (3H) |
| luminance | 700 cd/m² (Typ.) |
| contrast ratio | 1100:1 (Typ.) (TM) |
| view direction | Symmetry |
| response time | 8 (Typ.)(G to G) |
| viewing angle | 89/89/89/89 (Min.)(CR≥10) |
| operating mode | IPS, Normally Black, Transmissive |
| support color | 1.07B 98% sRGB |
| light source | WLED , 50K hours , With LED Driver |
| weight | 15.04Kgs (Typ.) |
| designed for | Digital Signage Outdoor High Brightness Stretched Bar LCD |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | V-by-One 8 lane , 51 pins Connector |
| power supply | 12.0V (Typ.) |
| environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
