| Nama Wahi | LD470DXS-SCA1 |
| Waitohu | LG Display |
| Rahi | 47 |
| Taupānga | DID |
| Whakatau | 1366×768 |
| Te tito | LCM |
| Tirohanga | 800 |
| CR | 1400:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | LG Display |
| panel model | LD470DXS-SCA1 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 47 inch |
| resolution | 1366(RGB)×768 , WXGA |
| display mode | S-IPS, Normally Black, Transmissive |
| active area | 1039.87×584.64 mm |
| outline | 1046.8×591.6×50.5 mm, Videowall Seam 6.9 mm |
| surface | Hard coating (3H), Reflection 2.0% (Max.) |
| brightness | 800 cd/m² (Typ.) |
| contrast ratio | 1400:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193172% |
| response time | 12 (Typ.)(G to G) |
| viewing angle | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| input voltage | 12.0V (Typ.) |
| application | DID |
