LC470WUF-SBF1

LC470WUF-SBF1
LC470WUF-SBF1
LC470WUF-SBF1 thumb LC470WUF-SBF1 thumb
Waitohu
LG Display
Rahi
47
Taupānga
LCTV
Whakatau
1920×1080
Te tito
LCM
Tirohanga
400
CR
1200:1
Nga Tae
16.7M/1.06B
Whakamuri
CCFL
Atanga
LVDS
In Stock
15983
Whakatakotoranga

Nama Wahi LC470WUF-SBF1
WaitohuLG Display
Rahi47
TaupāngaLCTV
Whakatau1920×1080
Te titoLCM
Tirohanga400
CR1200:1
Nga Tae16.7M/1.06B
WhakamuriCCFL
AtangaLVDS
panel brandLG Display
panel modelLC470WUF-SBF1
panel type a-Si TFT-LCD , LCM
panel size47 inch
resolution1920(RGB)×1080 , FHD
display modeS-IPS, Normally Black, Transmissive
active area1039.68×584.82 mm
outline1096×640 mm
surfaceAntiglare, Hard coating (2H)
brightness400 cd/m² (Typ.)
contrast ratio1200:1 (Typ.)
display colors16.7M/1.06B (8-bit / 8-bit + FRC)
response time4 (Typ.)(G to G); 6 (Typ.)(MPRT)
viewing angle89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
frequency120Hz
lamp type11 pcsCCFLWithout Driver
signal interfaceLVDS (4 ch, 8/10-bit), 92 pins
input voltage12.0V (Typ.)
applicationLCTV
