LC470EUD-SDF1

LC470EUD-SDF1
LC470EUD-SDF1
LC470EUD-SDF1 thumb LC470EUD-SDF1 thumb
Waitohu
LG Display
Rahi
47
Taupānga
LCTV
Whakatau
1920×1080
Te tito
LCM
Tirohanga
400
CR
1600:1
Nga Tae
16.7M/1.06B
Whakamuri
WLED
Atanga
LVDS
In Stock
40
Whakatakotoranga

Nama Wahi LC470EUD-SDF1
WaitohuLG Display
Rahi47
TaupāngaLCTV
Whakatau1920×1080
Te titoLCM
Tirohanga400
CR1600:1
Nga Tae16.7M/1.06B
WhakamuriWLED
AtangaLVDS
panel brandLG Display
panel modelLC470EUD-SDF1
panel type a-Si TFT-LCD , LCM
panel size47 inch
resolution1920(RGB)×1080 , FHD
display modeS-IPS, Normally Black, Transmissive
active area1039.68×584.82 mm
outline1078.6×626 mm
surfaceAntiglare (Haze 10%), Hard coating (2H)
brightness400 cd/m² (Typ.)
contrast ratio1600:1 (Typ.)
display colors16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172%
response time5 (Typ.)(G to G), 6 (Typ.)(MPRT)
viewing angle89/89/89/89 (Min.)(CR≥10)(L/R/U/D)
frequency120Hz+120Hz
lamp typeWLEDEmbedded (LED Driver)
signal interfaceLVDS (4 ch, 8/10-bit), 92 pins
input voltage12.0V (Typ.)
applicationLCTV
